If the route descends throughout
Guardian 60 stays in contention. Check the actual outlet and connector, then whether the screen will be reachable in that position. The owner’s approximate outlet height is a prompt to measure, not a specification for an improvised support.
If the route must rise
Guardian 60 does not serve that gravity route. Ask for the current 60P pump limits and full routing instructions. Hose length and lift are separate measurements; the supplied hose cannot supply the missing elevation limit.
| Installation question | Guardian 60 | Guardian 60P |
|---|---|---|
| Drainage | Gravity only | Gravity/pump advertised |
| Capacity | 60 at 80°F/60% RH on sheet | 60 AHAM-labeled page claim; basis unverified |
| Dimension order | 21.3 × 11.7 × 14.1 in on sheet | 21.3 × 14.1 × 11.7 on page; axes unresolved |
| Owner-use evidence | Low outlet, sleeping display and mixed sound reports | No exact-model reports inspected |
After the drainage decision, retain the remaining uncertainty: Guardian 60’s screen and sound observations cannot be transferred to 60P, and the different printed dimension order needs labeled axes. Do not use the resemblance between cabinets as the installation answer.
